Beta Draft Confidential
10-841/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM PVCs
Configuring PMP Circuits
Figure 10-26. Add Point-to-Multipoint PVC Leaf: Administrative Tab
2. Complete the Administrative tab fields as described in Table 10-17.
3. In the Add Point-to-Multipoint PVC Leaf dialog box, select the Accounting tab
(Figure 10-27 on page 10-85).
Table 10-17. Add Point-to-Multipoint PVC Leaf: Administrative
Tab Fields
Field Action/Description
Admin Status Set the Admin Status to Up if you want to
activate this circuit when the switch comes
online. Set the Admin Status to Down if you do
not want to activate this circuit when the switch
comes online.
VPI (0-255)
VCI (1-1023)
In the VPI (0-255) and VCI (1-1023) fields,
enter the VPI and VCI for the PMP circuit as
appropriate (VPCs do not require a VCI).
