A-41/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Adjusting the CAC
Configuring the CAC
Beta Draft Confidential
Configuring the CAC
This section describes how to tune the Lucent Call Master CAC to achieve the desired
cell loss ratio objective across all physical ports on a switch.
To configure the CAC parameters:
1. Right-click on the Switch instance node for the switch for which you want to
adjust the CAC, and select Set CAC Parameters from the pop-up menu.
The Set All CAC Parameters dialog box appears (Figure A-1).
Figure A-1. Set All CAC Parameters Dialog Box
2. Select one of the following CAC Type field options from the pull-down list:
Lucent — Enables you to tune the CLR and CDV only. See “Tuning the CAC” on
page A-5 for more information.
Customized VBRnrt and ABR — Enables you to tune the CLR, CDV, and
customized CAC parameters.
Customized VBRrt, VBRnrt, and ABR — Enables you to tune customized
CAC parameters only.
