Beta Draft Confidential
14-121/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring Fault-tolerant PVCs
Configuring APS Resilient UNI
4. Select ATM UNI (DCE or DTE) as the LPort Type from the pull-down list.
5. Complete the additional attributes as follows:
6. Choose OK to save the logical port and close the Add Logical Port dialog box.
Defining ATM UNI Logical Ports on the Protection Ports
To configure an ATM UNI logical port on an APS protection port:
1. Select the switch on which the first working port pair resides. (You will define an
ATM UNI logical port for each of these physical ports.)
2. Select the protection port (of the APS pair) and expand the instance node for the
PPort, subport, channel, card (MLFR type LPort), or IMA group to which you
want to add an LPort.
The LPorts class node appears under the PPort or subport instance node.
3. Right-click on the LPorts class node and select Add from the pop-up menu.
The Add Logical Port dialog box appears (Figure 3-5 on page 3-8).
4. Repeat step 4 through step 6 in the previous section, titled “Defining ATM UNI
Logical Ports on the Working Ports.” When you set the General tab Attributes for
this protection port, be sure to select Yes in the Can Backup Service Name field
(Table 3-2 on page 3-16).
5. Choose OK to save the logical port and close the Add Logical Port dialog box.
To Set... See...
General Attributes Table 3-2 on page 3-16
Administrative Attributes Table 3-3 on page 3-21
ATM Attributes Table 3-4 on page 3-29
ILMI/OAM Attributes Table 3-5 on page 3-35
VPI Range Attributes Table 3-7 on page 3-46
QoS Attributes Table 3-9 on page 3-53
