Beta Draft Confidential
7-181/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring Trunks
Working With Trunks
Working With Trunks
This section contains procedures to configure ATM direct trunks and ATM OPTimum
trunks.
Adding a Trunk
To add a trunk:
1. In the Networks object tree, expand the instance node for the network that
contains the switch.
2. Expand the Switches node.
3. Double-click on the switch to which you want to add a logical port. The Switch
tab is displayed.
4. Right-click on the Trunks node, and select Add from the pop-up menu as shown in
Figure 7-4.
Figure 7-4. Adding a Trunk
Note – Certain trunk attributes are defined as non-disruptive. Non-disruptive
attributes appear in italicized text in Navis EMS-CBGX dialog boxes.
When you modify any of these attributes, the NMS sends the appropriate SNMP SET
commands to the switch without bringing down the trunk and its associated logical
port. Switch parameter random access memory (PRAM) and the NMS database are
synchronized automatically, without interrupting network traffic.
When you modify any attributes other than non-disruptive attributes, the NMS will
bring down the trunk and its associated logical port.
