Beta Draft Confidential
D-141/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
ATM FCP Rate Profile Tables
MCR Class Mappings
OC-12/STM-4 IOM MCR Class Mapping
Table D-5 shows the MCR ranges and corresponding MCR classes for OC-12/STM-4
IOMs.
Table D-5. OC-12/STM-4 IOM MCR Class Mapping
MCR Range MCR Class MCR Range MCR Class MCR Range MCR Class
100 - 1023 1 12800 - 13311 25 25088 - 25599 49
1024 - 1535 2 13312 - 13823 26 25600 - 26111 50
1536 - 2047 3 13824 - 14335 27 26112 - 26623 51
2048 - 2559 4 14336 - 14847 28 26624 - 27135 52
2560 - 3071 5 14848 - 15359 29 27136 - 27647 53
3072 - 3583 6 15360 - 15871 30 27648 - 28159 54
3584 - 4095 7 15872 - 16383 31 28160 - 28671 55
4096 - 4607 8 16384 - 16895 32 28672 - 29183 56
4608 - 5119 9 16896 - 17407 33 29184 - 29695 57
5120 - 5631 10 17408 - 17919 34 29696 - 30207 58
5632 - 6143 11 17920 - 18431 35 30208 - 30719 59
6144 - 6655 12 18432 - 18943 36 30720 - 31231 60
6656 - 7167 13 18944 - 19455 37 31232 - 31743 61
7168 - 7679 14 19456 - 19967 38 31744 - 32255 62
7680 - 8191 15 19968 - 20479 39 32256 - 32767 63
8192 - 8703 16 20480 - 20991 40 32768 - 33791 64
8704 - 9215 17 20992 - 21503 41 33792 - 34815 65
9216 - 9727 18 21504 - 22015 42 34816 - 35839 66
9728 - 10239 19 22016 - 22527 43 35840 - 36863 67
10240 - 10751 20 22528 - 23039 44 36864 - 37887 68
10752 - 11263 21 23040 - 23551 45 37888 - 38911 69
11264 - 11775 22 23552 - 24063 46 38912 - 39935 70
11776 - 12287 23 24064 - 24575 47 39936 - 40959 71
