Configuring ATM Over MPLS Trunks
Configuring the ATMoMPLS Trunk
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/058-45
5. Provide the following information for both Endpoint 1 and Endpoint 2 fields:
a. Select the names of the two switches on which you configured ATMoMPLS
Trunk logical ports.
b. Expand the LPorts class node.
c. Select the first and second ATMoMPLS Trunk logical ports.
d. Review the LPort Type field. Both endpoints must use the same ATMoMPLS
Trunk logical port type.
e. Review the LPort Bandwidth (Kbps) field for each endpoint. The bandwidth
for each logical port endpoint must be the same.
6. Choose OK to return to the Add Trunk dialog box.
7. Complete the fields in the Administrative tab of the Add Trunk dialog box as
described in Table 8-13.
Trunk IP Routing, Trunk IP Area ID, and TOS 0 Metric parameters are not
available when configuring ATMoMPLS trunks.
Table 8-13. Add Trunk: Administrative Tab
Field Action/Description
Trunk Name Enter a unique alphanumeric name to identify the trunk.
Trunk Type Select the type of trunk backup services this trunk provides from
the pull-down list. Options include:
• Normal – Indicates that this trunk offers no backup service.
• Primary – Indicates that this trunk will act as the main trunk
connection in a backup service.
• Backup – Indicates that this is the trunk to which traffic will
be diverted in the event of primary trunk failure.
If you are configuring APS trunk backup for a CBX 500 or GX
550 switch, follow the instructions in “Configuring APS Trunk
Backup and Fast APS 1+1 for ATM Direct Trunks” on
page 7-29.
Administrative Cost
(1-65534)
Enter a value (from 1 - 65534) that defines the cost of using this
trunk for a VC when a VC is being dynamically created on the
switch.
Note: Modifying the value for this attribute does not bring down
the trunk or the associated logical port.
Keep Alive Error
Thresh (3-255)
Enter a value between 3 and 255 seconds to define the Keep
Alive (KA) error threshold. The default is 5 seconds. Service is
disrupted if you modify this value once the trunk is online.
