9-181/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Gateway Solution on CBX 3500
Configuring a Layer 2 Tunnel Over MPLS Core Network
Table 9-5. Modify Switch: MPLS Tab Fields
Field Description
MPLS Admin Status Set the MPLS Admin Status as follows:
• Up – (default) Activates MPLS on the switch.
• Down – Saves the configuration in the database without
activating MPLS on the switch.
IP Vpn Not available for this release.
LSR ID The LSR ID is the valid IP address for local and remote ends of the
Layer 2 tunnel.
Select an available LSR ID from the pull-down list box. This is the
LSR router ID used by RSVP-TE. This field must be set before any
other MPLS configuration can be done on this switch. Once any
MPLS configuration occurs (for instance, MPLS tunnels or LDP
sessions) this field may not be changed unless the other MPLS
configuration is deleted.
This field will not be available if the User Configured LSR ID box
is checked.
User Configured
LSR ID
To enter the IP address of the LSR, check the User Configured
LSR ID box, then enter the IP address of the LSR ID assigned to
this switch.
Static Label Max
(0 or 16-65535)
The static label maximum is defined within a label range of zero
(0)-65535. Zero (0) - 16 is reserved for MPLS.
Set the maximum label to be used by static configuration of PSN
tunnels, PWE3 and Layer 2 tunnels.
The range of labels between the maximum value set and 65535 will
be used for RSVP-TE and LDP signaling.
Mpls Tunnel Traps
Enabled
Check the box to enable MPLS tunnel Up/Down SNMP traps. For
more information on traps, see the Switch Diagnostics User’s
Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000.
Mpls Cross
Connection Traps
Enabled
Check the box to enable MPLS cross connection Up/Down SNMP
traps. For more information on traps, see the Switch Diagnostics
User’s Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000.
Tunnel Notification
Rate (1-Max)
Define the rate of MPLS tunnel and cross connect trap notifications
per second. The range is 1-2147483648.
