Configuring SVC Parameters
Configuring SVC Attributes
Connection ID Attributes for SVCs
The VPI/VCI address range fields allow you to design a VPC VPI or VCC VPI/VCI
address range to match the capability of the equipment attached to this port.
1. From the Configure SVC dialog box, select the Connection ID tab (Figure 17-12).
2. Complete the fields in the Connection ID tab, as described in Table 17-7.
IE Sig Override Mask This parameter enables the switch to override the standard
signaling protocol for specific information elements at this
logical port. If an IE’s corresponding bit is set, the
information element is always signaled. If an IE bit is
cleared, the IE may or may not be sent out, but the decision
will be based on the standard signaling protocol.
Select one of the following check boxes, depending on
how you wish to configure this SVC endpoint:
Called Party — Remote address where the call is
terminating (egress address).
Calling Party — Remote address where the call is
initiated (source address).
User-User — Between calling party and called party.
Table 17-6. Configure SVC: Address Tab Fields (Continued)
Field Description
Note – If you are using the Enhanced Channelized IMA IOM in DS3 or STM-1
mode, and when configured in UNI mode, the default SVC Connection ID Range is
zero (0) to 255. The corresponding default values for Number of Valid Bits in VCI (6)
and Number of Valid Bits in VPI (8) are displayed in the ATM tab, as described in
Table 3-4 on page 3-29. When the Enhanced Channelized IMA IOM in DS3 mode is
configured in IMA mode, the standard SVC Connection ID Parameters default values
are used.
