Downloading Buffer Threshold and Rate Profile Tables
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/056-9
Beta Draft Confidential
Figure 6-2. Selecting Load Profile
The Load Rate Profile Tables dialog box appears (Figure 6-3).
Figure 6-3. Load Rate Profile Tables Dialog Box
Note – If the Enable ATM Flow Control Processor check box is not checked in the
card attributes, the Load Profile menu option will not be available. Once this field is
enabled, the FCP attribute fields will be available on the Modify Card dialog box (see
Figure 6-1 on page 6-3).
Access the Modify Card dialog box and enable ATM FCP using the steps in “Enabling
the FCP” on page 6-2.
