Configuring PNNI Routing
PNNI Policy-based Routing
6. Choose OK to save the settings and close the Add VPN dialog box.
Table 21-3. Add VPN:General Tab Fields
Field Description
Type Select Layer2 (the default).
Name Enter a name for the VPN.
Comments Enter any comments about this VPN.
Set PNNI Policy Routing Attributes Select the check box to specify the policy
routing attributes.
Ne-NSC (1-65535) Enter a number to identify the policy
Network Entity NSC to be used in a policy
constraint for a policy routed call on this
VPN.
Rp-NSC (1-65535) Enter a number to identify the Resource
Partition NSC to be used in a policy
constraint for a policy routed call on this
VPN.
If the Is Public NeNSC button is set to Yes,
the Rp-NSC field will be unavailable.
Is Public NeNSC? Choose Yes to allow this Ne-NSC to be a
public Ne-NSC. This Ne-NSC can then be
used to tag PNNI links. The PNNI link,
tagged with Public Ne-NSC, will then be
advertised with bare resources and can be
used by calls with no policy or with Private
Net Overflow Public.
Choose No (default) to enter Ne-NSC and
Rp-NSC for a private VPN.
Note - Only one Ne-NSC value is allowed to
be defined as public.
