Beta Draft Confidential
Configuring ATM Over MPLS Trunks
Configuring the ATMoMPLS Trunk
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/058-43
Configuring the ATMoMPLS Trunk
After you have defined feeder and ATMoMPLS Trunk logical ports, you can configure
the ATMoMPLS trunk. The trunk is configured between two ATMoMPLS trunk
logical ports.
To configure an ATMoMPLS trunk between two Lucent switches using Navis
EMS-CBGX:
1. In the Navis EMS-CBGX window, select the Trunks node.
You can access the Trunks node from the switch, or from an LPort node. When
you create a trunk from an LPort node, the selected LPort is automatically set as
Endpoint 1 of the new trunk.
Figure 8-23. Managing Trunks
2. Perform one of the following:
• Select Add from the Actions menu.
• Choose the Add button from the toolbar.
• Right-click the Trunks node and select Add from the popup menu.
The Add Trunk dialog box appears (Figure 8-24).
