Beta Draft Confidential
4-42 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Logical Ports on Frame-based Modules
Defining ATM Network Interworking for Frame Relay NNI Logical Ports
Defining ATM Network Interworking for Frame Relay
NNI Logical Ports
Before you configure an ATM Network Interworking for FR NNI logical port, first
configure an ATM UNI DTE feeder logical port with a minimal amount of bandwidth
on the same physical port.
To define an ATM Network Interworking for FR NNI logical port:
1. Complete the fields in the Add Logical Port dialog box (Figure 4-1 on page 4-15)
as follows:
LPort Name — Enter a unique alphanumeric name for this logical port.
Service Type — ATM is selected by default.
LPort Type — Select ATM Network Interworking for FR NNI.
2. Complete the fields in the remaining tabs as described in Table 4-17.
When you finish setting these attributes, continue with the section, “Completing
the Logical Port Configuration” on page 4-52.
Table 4-17. Configuring Network Interworking for Frame Relay NNI
Attributes
For 1-port ATM CS DS3/E3 or 1-port
ATM IWU OC-3c/STM-1 cards see...
For frame-based cards see...
“Defining ATM UNI DCE/DTE Logical
Ports” on page 4-15
“Defining ATM UNI DCE/DTE
Logical Ports” on page 4-15
“Link Management Attributes” on page 4-43 “ATM Attributes” on page 4-21
“Trap Control Attributes” on page 4-31 “Link Management Attributes” on
page 4-43
“Discard/Congestion Mapping Attributes” on
page 4-47
“Trap Control Attributes” on
page 4-31
“Priority Frame Attributes” on
page 4-34
