Configuring ATM PVCs
About the PVC Tabs
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-33
Completing the PVC Configuration
Use the following steps to complete the circuit configuration.
1. (Optional) To configure CBX 500 or GX 550 Network Data Collection (NDC)
parameters for this circuit, select the NDC tab. For more information, see the
Switch Diagnostics User’s Guide
for CBX 3500, CBX 500, GX 550, and B-STDX 9000.
2. (Optional) To configure NavisXtend Accounting Server parameters for this
circuit, choose the Accounting tab. For more information, see the NavisXtend
Accounting Server Administrator’s Guide.
3. Optional) To manually define the circuit path for this circuit, choose the Path tab.
See “Manually Defining the Circuit Path” on page 10-68 for more information.
4. (Optional) To configure this PVC for a specific Layer2 VPN and customer, see
page 13-9.
5. To add more PVCs, repeat the steps in “Defining a Point-to-Point Circuit
Connection” on page 10-13.
6. When you finish, choose OK to define the circuit parameters. The Add PVC
dialog box closes.
Note – If enabled, the Reliable Scalable Circuit feature verifies the card state of each
PVC endpoint before sending the
SNMP Set command. If the card status at either
endpoint is not up, the NMS displays an error message indicating where the failure
occurred. If you receive such a message, see Appendix F, “Reliable Scalable Circuit,”
for more information.
