Beta Draft Confidential
8-281/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Trunks
Configuring Feeder Logical Ports
QoS Tab
When configuring Bandwidth Allocation settings for feeder logical ports, the
Dynamic option is enabled by default, with 0% values. The QoS tab in the Add
Logical Port dialog box is shown in Figure 8-14.
Figure 8-14. Add Logical Port: QoS Tab
For ATMoMPLS UNI/NNI feeder logical ports, you can configure the fields in the
QoS tab as described in Table 8-7.
Table 8-7. Add Logical Port: QoS Tab Fields
Column Action/Description
Class For each row in the table, this column displays the QoS class to
which settings in other columns relate.
