Configuring SVC Parameters
Configuring SVC Attributes
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-13
Setting Logical Port Signaling Tuning Parameters
This section describes how to modify the signaling tuning parameters for an ATM
UNI logical port. For more information on logical port signaling, see page 2-6.
To modify the signaling tuning parameters:
1. From the Configure SVC dialog box, select the Signaling Tab (Figure 17-5 on
page 17-11), then choose the Tuning Parameters button. The SVC Signaling
Tuning dialog box appears (Figure 17-6).
Figure 17-6. SVC Signaling Tuning Dialog Box
Use the SVC Signaling Tuning dialog box to set the Q.2931 thresholds and timers,
and the Q.SAAL protocol data unit (PDU) thresholds and timers. In general, you
should not change the default values. The displayed defaults are based on the
ATM protocol you selected for the logical port (see page 3-31).
Proxy Agent Choose this button to have this LPort act as a proxy
agent for other clients.
Tuning Parameters Choose this button to launch the SVC Signaling Tuning
dialog box (Figure 17-6 on page 17-13).
Table 17-3. Configure SVC: Signaling Tab Fields (Continued)
Field Description
