Beta Draft Confidential
18-61/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
Defining a Point-to-Point Offnet Circuit Connection
When working with SPVCs, you can configure a connection that is point-to-point or
PMP. This section covers point-to-point ATM SPVCs, configured through the Navis
EMS-CBGX Offnet Circuits option. To configure a PMP offnet circuit, see “Defining
a PMP SPVC (Offnet Circuit)” on page 18-30.
You access the Offnet Circuits node from the Circuits node. You can access the
Circuits node from the switch, or from an LPort node. When you create an Offnet
Circuit from an LPort node, the selected LPort is automatically set as the Endpoint 1
of the new Offnet Circuit.
To open the Add Offnet Circuit dialog box:
1. Expand the Circuits node.
2. Select the Offnet Circuits node.
3. Right-click the Offnet Circuits node and select Add from the pop-up menu.
The Add OffNet Circuit dialog box appears (Figure 18-1).
Figure 18-1. Add OffNet Circuit Dialog Box
