Table 9-10 describes the fields and controls in the Trap Control tab.
Table 9-10. Add Logical Port: Trap Control Tab
Field Description
Congestion (%)
(10-100)
Enter a value between 0 and 100 to indicate the threshold
percentage for generating and sending traps to the NMS for this
logical port. A congestion trap is generated and sent to the NMS if
the rate of congestion over a one-minute period exceeds the
percentage value you enter.
Adjust the entered value according to how sensitive this port needs
to be to network congestion. Options include:
• Low – Generates a trap at the first sign of congestion.
• High – Generates traps for serious network congestion.
• Zero – (default) Disables congestion threshold. If you enter
zero, no traps are generated for this logical port.
Frame Err/Min
(0-13684)
Enter a value from 0 to 16384 to configure the threshold of frame
errors on this logical port. If the number of frame errors received in
one minute exceeds the specified number, a trap is sent to the NMS.
Adjust this value according to how sensitive this port needs to be to
frame errors. A lower value will make the port sensitive to frame
errors. A high value will generate traps when a significant number
of frame errors occur within a one-minute period.
A value of zero (default) disables this feature, which prevents traps
from being generated for this logical port.
