Beta Draft Confidential
Configuring ATM PVCs
Configuring PMP Circuits
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-81
Defining PMP Circuit Leafs
You access the PMP Leaves class node from the PMP Roots Class node, which falls
under the Circuits class node. You can access the Circuits class node from the switch
or from an LPort instance node. When you create a PMP PVC Leaf from an LPort
instance node, the selected LPort is automatically set as the PMP PVC Leaf Endpoint.
The following steps describe the process for creating a new point-to-multipoint (PMP)
PVC leaf:
1. “Opening the Add Point-to-Multipoint PVC Leaf Dialog Box” on page 10-81.
2. “Selecting a PMP PVC Leaf Endpoint” on page 10-83.
3. “Configuring PMP PVC Leaf Parameters” on page 10-83.
Opening the Add Point-to-Multipoint PVC Leaf Dialog Box
To open the Add Point-to-Multipoint PVC Leaf dialog box:
1. Expand the Circuits class node.
2. Expand the PMP Roots class node.
3. Expand the desired PMP Root.
4. Select the PMP Leaves class node.
5. Perform one of the following:
• Select Add from the Actions menu.
• Choose the Add button from the toolbar.
• Right-click the PMP Leaves class node and select Add from the pop-up menu.
The Add Point-to-Multipoint PVC Leaf dialog box appears (Figure 10-25).
