Beta Draft Confidential
Configuring SPVCs
Defining a PMP SPVC (Offnet Circuit)
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0518-33
Administrative Attributes
To configure offnet PMP PVC root administrative attributes:
1. In the Add Offnet Point-to-Multipoint PVC Root dialog box, select the
Administrative tab (Figure 18-14).
Figure 18-14. Add Offnet Point-to-Multipoint PVC Root:
Administrative Tab
2. Complete the Administrative tab fields in the Add Offnet Point-to-Multipoint
PVC Root dialog box as described in Table 18-9.
Table 18-9. Add Offnet Point-to-Multipoint PVC Root:
Administrative Tab Fields
Field Action/Description
Root Name Enter any unique, alphanumeric name to identify the Offnet circuit root.
Do not use parentheses and asterisks.
Circuit Type Specify whether the circuit is a VPC or VCC (default).
If you choose the VPC button, the VCI field is set to zero (0) and cannot
be changed.
