Beta Draft Confidential
Configuring SVC Parameters
Configuring SVC Attributes
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-17
4. Complete the fields as described in Table 17-5.
5. Choose the Peer Client & Agent button.
The Peer Client & Agent dialog box appears (Figure 17-8).
Figure 17-8. Peer Client & Agent Dialog Box
Table 17-5. Add Management VPCI Table Entry Dialog Box Fields
Field Description
Peer Client & Agent Choose this button to launch the Peer Client
dialog box, in which you choose the proxy
signalling client.
Active Select the check box to assign the VPCI/VPI
combination to the proxy signalling client.
Remove the check from the box to save this
VPCI/VPI combination in the database for later
use.
VPCI (0-65534) Enter the VPCI value for the proxy signalling
client.
VPI (0-4096) Enter the VPI value for the proxy signalling
client.
