6-21/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuration Process Overview
Beta Draft Confidential
Configuration Process Overview
Perform the following steps to configure the FCP:
Enabling the FCP
This section describes how to enable and configure the FCP on an IOM.
To enable the FCP:
1. Expand the network that includes the desired switch.
2. Expand the switch on which you want to enable FCP.
3. Expand the Cards class node under the desired switch.
4. Expand the desired card node.
5. Perform one of the following:
• Select Modify from the Actions menu.
• Choose the Modify button from the toolbar.
• Right-click on the card instance node and select Modify from the pop-up
menu.
The Modify Card dialog box appears (Figure 6-1).
Step 1. Enable the ATM FCP. See “Enabling the FCP” below.
Step 2. Download buffer threshold and rate profile tables. See “Downloading Buffer
Threshold and Rate Profile Tables” on page 6-8.
Step 3. Configure logical port FCP attributes. See “Setting Logical Port FCP Attributes”
on page 6-10.
Note – Contact a qualified Lucent organization for network design validation before
enabling the FCP.
