Lucent Technologies CBX 3500 - Table 9-4. Add Diffserv Dialog Box Fields

Beta Draft Confidential
9-141/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Gateway Solution on CBX 3500
Network-wide MPLS Settings
Table 9-4. Add DiffServ Dialog Box Fields
Field Description
Name Enter an alpha-numeric name for this DiffServ profile.
ID The Diffserv ID is a read-only field. It is incremented
automatically as DiffServ profiles are created.
L-LSP Properties (L-LSP type only)
L-LSP PSC The QoS of LSP is derived from the PSCID. CBX 3500
supports eight PSCIDs that determine the type of forwarding
required on the LSP.
Select from the following PSCIDs:
• DF-Drop Precedence0 – typically used for UBR/ABR
with CLP 0
• DF-Drop Precedence1 – typically used for UBR/ABR
with CLP 1
• AF1-Drop Precedence0 – typically used for VBR-Nrt
with CLP 0
• AF1-Drop Precedence1 – typically used for VBR-Nrt
with CLP 1
• AF2-Drop Precedence0 – typically used for VBR-RT
with CLP 0
• AF2-Drop Precedence1 – typically used for VBR-RT
with CLP 1
• EF-Drop Precedence0 – typically used for CBR with
CLP 0
• EF-Drop Precedence1 – typically used for CBR with
CLP 1
E-LSP Properties (E-LSP type only)
E-LSP NUM
PHB(0-8)
Select a number from 0-8 (default). This defines the number
of PHBs to be signaled.
