Beta Draft Confidential
9-501/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Gateway Solution on CBX 3500
Configuring a Layer 2 Tunnel Over MPLS Core Network
Table 9-20. Add Tunnel: Static Tab Fields
Field Description
Admin Status The admin status to indicate whether this static tunnel
cross-connect should be used for forwarding (Up) or not (Down)
from the source LSR ID to the destination LSR ID. The default is
Up.
Input Interface Endpoint 1 – This field is only used when the Tunnel Set option is
configured for the tunnel. This field should be set to the incoming
interface for the egress tunnel starting at the destination LSR ID
and terminating on the source LSR ID.
Endpoint 2 – This field should be set to the incoming interface for
this egress tunnel from the source LSR ID to the destination LSR
ID.
Output Interface Endpoint 1 – This field should be set to the outgoing interface for
this ingress tunnel from the source LSR ID to the destination LSR
ID.
Endpoint 2 – This field is only used when the Tunnel Set option is
configured for the tunnel. This field should be set to the outgoing
interface for the ingress tunnel starting at the destination LSR ID
and terminating on the source LSR ID.
Input Label Endpoint 1 – This field is only used when the Tunnel Set option is
configured for the tunnel. This field should be set to the incoming
label on the input interface corresponding to the egress tunnel
which starts at the destination LSR ID and terminates on the source
LSR ID.
Endpoint 2 – This field should be set to the desired label to be used
on the incoming interface for this tunnel.
Output Label Endpoint 1 – This field should be set to the label to be used on the
outgoing interface for this tunnel.
Endpoint 2 – This field is only used when the Tunnel Set option is
configured for the tunnel. This field should be set to the outgoing
label on the output interface corresponding to the ingress tunnel
which starts at the destination LSR ID and terminates on the source
LSR ID.
