Beta Draft Confidential
Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0518-11
Configuring Offnet Circuit Parameters
To configure Offnet Circuit parameters, enter information in the following tabs,
categorized by parameter type:
• Administrative (page 18-11)
•Traffic Type (page 18-15)
• User Preference (page 18-21)
• Accounting (page 18-22)
•Path (page 18-24)
• FRF.5 (page 18-27)
Administrative Attributes
1. In the Add OffNet Circuit dialog box, select the Administrative tab (Figure 18-4).
Figure 18-4. Add OffNet Circuit: Administrative Tab
2. Complete the fields in the Administrative tab, as described in Table 18-4.
Note – Before you configure the parameters for an Offnet Circuit, you must select the
circuit endpoints (see “Selecting an Endpoint From a Switch” on page 18-7).
