Configuring SVC Parameters
Configuring SVC Attributes
Override Default (for
reverse signaling)
Select the check box to override the default TD for
reverse signaling. You can then select a different TD.
Remove the check from the box to use the default
Traffic Descriptor for reverse signaling. You will not be
able to select a different traffic descriptor.
Reverse: PMP Rev, Unsp
CBR
Choose a TD for reverse signaling. This field is enabled
only if you selected the Override Default check box (for
reverse signaling).
VPCI/VPI Mapping
VPI=VPCI Sets mapping to equal. The VPI equals the VPCI.
VPI=VPCI+ Sets mapping to positive offset. Text box allows entry
of integer offset. The VPI of the corresponding circuit
equals the VPCI plus the value you enter.
VPI=VPCI- Sets mapping to negative offset. Text box allows entry
of integer offset. The VPI of the corresponding circuit
equals the VPCI minus the value you enter.
Table Sets mapping to VPCI entry from the VPCI table for
the LPort. This option has additional functions that are
used with Proxy Signaling. For information on
configuring the VPCI table, see “Configuring a
Management VPCI Table Entry” on page 17-16.
Proxy Signaling
Enable Select the check box to enable proxy signaling for the
SVC.
Proxy Client
(for ATM UNI only)
Choose this button to use the proxy agent for signaling.
Use Proxy Agent on LPort Enter the LPort to use as a proxy agent by choosing the
following button:
Then, select an LPort from the list displayed.
Agent Node Id The ID of the switch to be used as the proxy signaling
agent.
Agent Interface Number The agent interface number assigned to the proxy
signaling agent.
Table 17-3. Configure SVC: Signaling Tab Fields (Continued)
