Beta Draft Confidential
17-101/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SVC Parameters
Configuring SVC Attributes
MBS (cells) The maximum MBS, in CPS, that may be signaled for a VBR-RT or
VBR-NRT ATM SVC. This attribute is used to qualify the forward
MBS signaled at the ingress logical port and the backward MBS
signaled at the egress logical port.
Enter a value between 0 - 2147483647 or accept the default value,
No Limit.
MBS No Limits Clear the MBS No Limits check box if you want to enter a value in
the MBS (cells/sec) column.
MCR (cells) The maximum MCR, in cells per second, that may be signaled for an
ABR ATM SVC. This attribute is used to qualify the forward MCR
signaled at the ingress logical port and the backward MCR signaled
at the egress logical port.
Enter a value between 0 - 2147483647 or accept the default value,
No Limit.
MCR No Limits Clear the MCR No Limits check box if you want to enter a value in
the MCR (cells/sec) column.
Table 17-2. TD Limits Dialog Box Fields (Continued)
Field Action/Description
