Configuring ATM Logical Ports on Frame-based Modules
Defining ATM Network Interworking for Frame Relay NNI Logical Ports
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/054-45
RLMI Binding
Active Enable
(
1-port
ATM IWU
OC-3c/STM-1
and 1-port ATM
CS DS3/E3
modules)
Enables or disables the RLMI administrative state.
If this checkbox is checked, RLMI is enabled. Enable this field to
provide resiliency by monitoring LMI link status by specifying a pair
of logical ports to serve as primary and backup ports. If the primary
port fails, a switchover to the backup port occurs.
If you enable RLMI on a Frame Relay UNI DTE or NNI port, you can
configure the RLMI Max Full Status Attempts. If you enable RLMI,
you cannot set LMI to Disabled.
Notes: You cannot disable RLMI or delete a logical port if the logical
port is configured in an RLMI service name binding.
If the LPort is configured as a member of a “Master” RLMI service
name binding, you can change the LPort type to Frame Relay UNI
DTE or NNI.
If the LPort is configured as a member of a “Slave” RLMI service
name binding, you can change the LPort type to Frame Relay UNI
DCE or NNI.
Changing the value for this attribute does not admin down the logical
port.
See Chapter 15 for more information about RLMI.
Table 4-18. Add Logical Port: Link Management Tab Fields (Continued)
Field Action/Description
