Beta Draft Confidential
7-541/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring Trunks
Configuring VNN OSPF
5. When you are done setting parameters, choose OK.
Modifying VNN External Route Aggregates
To modify an existing VNN external route aggregate:
1. Right-click on the instance node for the VNN external route aggregation you want
to modify, and select Modify from the pop-up menu.
The Modify VNN External Route Aggregation dialog box appears.
2. Modify the desired parameters. Only Metric Type and Advertise Matching fields
may be modified.
3. When you are done modifying fields, choose OK to save the changes.
The Modify VNN External Route Aggregation dialog box closes.
Note – VNN OSPF external aggregation will aggregate only those type-5 routing
entries that match the Type configured in external aggregation. For example, if routes
are configured as:
10.10.1.1. and 10.10.1.2 as Type 1, and 10.10.1.4 as Type 2,
then aggregation configured with Net of 10.10.0.0, Mask of 255.255.0.0, Type 1, and
Advertising Matching disabled, then only 10.10.1.1 and 10.1.1.2 will aggregate as
10.10.0.0. The route of 10.10.1.4 will not be affected since the Type does not match
the configured aggregate.
