Beta Draft Confidential
Configuring ATM Over MPLS Gateway Solution on CBX 3500
Configuring a Layer 2 Tunnel Over MPLS Core Network
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/059-33
4. When you complete the configuration, choose OK to save the changes and close
the dialog box.
Forwarding
Policy Admin
Status
Select one of the following options:
Enable – (default) Enables the use of forwarding policies for the
logical port.
Disable – Disables the use of forwarding policies for the logical
port.
Unnumbered
Interface
Not supported on ULC POS PPP LPorts.
IP Forwarding
Unicast Select one of the following options:
Enable – (default) Specifies that IP forwarding will be allowed
from this logical port to a unicast address.
Disable – Indicates that IP forwarding will not be allowed from
this logical port to a unicast address. The specific unicast
addresses are specified for each IP interface.
Broadcast Select one of the following options:
Enable – (default) Specifies that IP forwarding will be allowed
from this logical port to a broadcast address.
Disable – Specifies that IP forwarding is not allowed from this
logical port to a broadcast address. The specific broadcast
addresses are specified for each IP interface.
Table 9-13. Add IP LPort Fields (Continued)
Field Action/Description
Note – For more information on configuring IP logical ports, see the IP Services
Configuration Guide for CBX 3500, CBX 500, and B-STDX 9000.
