Configuring ATM PVCs
Configuring Frame Relay-to-ATM Interworking Circuits
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-59
Shaper ID
(B-STDX ATM
CS/IWU
endpoint only)
Choose the Select button to select a traffic shaper for the endpoint. Select
one of the configured shapers in the Select Traffic Shaper dialog box.
If this circuit carries ATM cell traffic, use the default of none. If this
circuit carries frame relay traffic, select one of the configured shapers.
These shapers correspond to the traffic shapers configured for the
physical port on which this logical port resides.
For information about physical port traffic shaping, see the Switch
Module Configuration Guide for CBX 3500, CBX 500, GX 550, and
B-STDX 9000.
Table 10-12. Add PVC: Traffic Type Tab Fields (Continued)
Field Action/Description
