Configuring SVC Parameters
Configuring SVC Attributes
Reverse Choose one of the buttons to set the discard priority for the SVC in
the reverse direction (the callee to caller direction of an SVC). When
a particular service category’s output queue becomes congested, it
must discard cells. The lower the number, the higher the priority. Set
this attribute from 1 (high priority) to 3 (low priority). The default is
2.
Bandwidth Allocation
QoS Class The four available QoS classes are listed in this column:
• CBR
• VBR RT
• VBR NRT
• UBR/ABR
Allowed (0-100%) Enter the bandwidth allocation percentage (between 0 and 100) for
each QoS class. The default is 100%.
Traffic Descriptor Limits
No Limits Select the check box if you do not want to set any TD limits
(default).
Clear the check box if you do want to set TD limits.
Specify Limits Choose the Specify Limits button if you do want to set TD limits. In
the dialog box that comes up, you can enter a value between 0 and
2147483647 CPS. See “Defining SVC TD Limits Attributes” on
page 17-9.
This button is not active until you clear the No Limits check box.
Table 17-1. Configure SVC: General Tab Fields (Continued)
Field Action/Description
