OSPF Area Summary Select the check box if the node represents an area border
router. Then enter an OSPF Area ID.
For more information, see the IP Services Configuration Guide
for CB 3500, CBX 500, and B-STDX 9000.
OSPF Area ID If you select the check box in the OSPF Area Summary field,
enter an OSPF Area ID. This assigns an OSPF area to a node
prefix in cases where the node acts as an area border router.
OSPF Area IDs enable the VC manager to determine which
way to route the PVC.
External Name: PNNI Select the check box to advertise this name within the PNNI
routing domain as an external name. An external name is a
name that is reachable within another PNNI routing domain.
If you clear the check box (default), this name is only reachable
within the PNNI routing domain.
External Name: VNN Select the check box to advertise this name within the VNN
routing domain as an external name. An external name is a
name that is reachable within another VNN routing domain.
If you clear the check box (default), this name is only reachable
within the VNN routing domain.
Suppress
Advertisement: PNNI
Select the check box to prevent advertising this address across
the PNNI domain.
If you clear the check box (default), this address will be allowed
to be advertised across the PNNI routing domain if the local
switch is connected to a PNNI peer group.
Suppress
Advertisement: OSPF
If you clear the check box (default), this address will be allowed
to be advertised across the VNN OSPF routing domain.
Select the check box to prevent advertising this address across
the VNN OSPF routing domain.
AdminCost (0-65535) Enter the administrative cost associated with the node prefix.
When an SVC is being created, if more than one node in the
network is found with the same node prefix, then the call is
routed to the node that has the lowest administrative cost
associated with the node prefix.
Table 17-10. Add SVC Node Prefix: General Tab Fields (Continued)
Field Action/Description
