Beta Draft Confidential
18-141/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
Path Trace Enable Path Trace – Select the check box to enable path trace for circuits
that pass through this logical port.
Clear the check box (default) to disable path trace.
Clear Call at Destination – A selected check box indicates that the
circuit will be deleted from the switch after the specified path trace
timeout period. Path trace information for this circuit will also be made
available for the timeout period.
An cleared check box indicates that the circuit will not be deleted from
the switch after the specified path trace timeout period.
CrankBack Info Required – Select the check box to enable collection of
crankback information for circuits that pass through this logical port.
Crankback information is information about dynamic rerouting of call
setups around failed nodes or links (or links with insufficient resources)
on the traced path.
Clear the check box (default) to disable crankback information
collection.
Pass Along Request – Select the check box to enable (default) pass along
request for circuits that pass through this logical port. When the path
trace continues through nodes that do not support the path trace feature,
the trace results may contain some gaps between successive entries of
logical nodes and logical ports traversed by this connection or party.
Clear the check box to disable pass along request. The path trace will
terminate at any switch that does not support the path trace feature. A
partial path trace will be returned.
Path Trace Timeout (sec)(1-65535) – Enter the number of seconds for
the path trace function to time out (for the trace results to be maintained
in the switch). The default is 10 minutes (600 seconds).
Table 18-4. Add OffNet Circuits: Administrative Tab Fields (Continued)
Field Action/Description
