Beta Draft Confidential
18-201/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
Shaper ID
(B-STDX ATM
CS/IWU
endpoint only)
Choose the Select button to select a traffic shaper for the endpoint.
Select one of the configured shapers in the Select Traffic Shaper dialog
box.
If this circuit carries ATM cell traffic, use the default of none (in the Id
column). If this circuit carries frame relay traffic, select one of the
configured shapers. These shapers correspond to the traffic shapers
configured for the physical port on which this logical port resides.
For information about physical port traffic shaping, see the Switch
Module Configuration Guide for CBX 3500, CBX 500, GX 550, and
B-STDX 9000.
Table 18-6. Add Offnet Circuit: Traffic Type Tab Fields (Continued)
Field Action/Description
