21-381/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring PNNI Routing
PNNI Policy-based Routing
To define the logical port for any other input/output module (IOM):
a. Expand the instance node for the card to which you want to add an LPort.
b. Expand the PPorts class node, then the PPort instance node.
3. Right-click on the LPorts class node and select Add from the pop-up menu.
The Add Logical Port dialog box appears (Figure 21-9).
4. Select the PNNI tab to display the PNNI parameters.
5. Select the Set PNNI Policy Routing Attributes check box if it’s not already
selected.
IMA group 3-Port Channelized DS3/1
IMA IOM
1.
Expand the 3-port Channelized
DS3 ATM IMA instance node, then
expand the PPorts class node.
2. Expand the IMA Groups class
node, then the IMA group instance
node.
3-port Channelized
DS3/1 ATM w/IMA
Enhanced IOM
1-port Channelized
STM-1/E1 IMA IOM
1-Port Channelized
STM1/E1 ATM w/IMA
Enhanced
Module/Configuration Steps
Set
Note – See the Switch Module Configuration Guide for CBX 3500, CBX 500, GX 550,
and B-STDX 9000 for information about configuring physical port, channel, and IMA
group attributes for the channelized DS3/1 and STM-1/E1 IMA modules on
CBX 3500 and CBX 500 switches.
