Beta Draft Confidential
Configuring CBX or GX Logical Ports
Working With ATM Logical Ports
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/053-7
To define the logical port for a CBX 3500 1-port OC-48c/STM-16c,
4-port OC-12c/STM4 ATM/POS, or 16-port OC-3/STM-1module:
a. Expand the instance node for the card to which you want to add an LPort.
b. Expand the PPorts class node, then expand the PPort instance node.
c. Expand the Subports class node, then the Subport instance node.
To define the logical port for any other I/O module (IOM):
a. Expand the instance node for the card to which you want to add an LPort.
b. Expand the PPorts class node, then the PPort instance node.
3. Right-click on the LPorts class node and select Add from the pop-up menu.
The Add Logical Port dialog box appears (see Figure 3-5).
Note – The product formerly called the GX 250 Multiservice Extender is now
referred to as the GX 550 ES (Extender Shelf) in the Navis EMS-CBGX Network
Management Station (NMS) interface.
The Navis EMS-CBGX NMS may display features that are not available in this
release. For a complete list and explanation of each of the features that are supported
in this release, see the Navis EMS-CBGX Software Release Notice (SRN).
