Reference Guide 472 Document #: LTRT-17939
Mediant MSBR
Command Description
Defines the SIP transport type.
Defines the Application Profile.
broken-connection-
Defines the duration
the RTP connection should be broken
before the Broken Connection event is issued [100ms].
busy-out
Enables trunks to be taken out of service in case of LAN
down.
Defines the Calling Number Play Back ID.
Defines the key sequence for call pickup.
call-transfer-using-
Enables Call Transfer using re-INVITEs.
calls-cut-through
Enables call connection without on-hook/off-hook process
'Cut-Through'.
Defines the CDR report timing.
Defines the Syslog server IP address for sending CDRs.
Defines the coder priority in SDP negotiation.
crypto-life-time-in-
Disables Crypto life time in SDP.
current-disc
Enables disconnect call upon detection of current
disconnect signal.
debug-level-high-
Defines the threshold for auto-switching of debug level.
Defines the default record location URI used by Media Ctrl
Defines the Gateway delay time after reset (seconds).
delay-b4-did-wink
Defines the delay between off-hook detection and Wink
generation (FXS).
Enables sending INVITE message with/without SDP offer.
dflt-release-cse
Defines the release cause sent to IP or Tel when device
initiates release.
Enables use of different RTP port after hold.
Enables DID lines using Wink.
digit-delivery-2ip
Enables automatic digit delivery to IP after call is
connected.
digit-delivery-2tel
Enables automatic digit delivery to Tel after line is off-
hooked or seized.
digit-pttrn-on-conn
Enables Play Code string to Tel when connect message
received from IP.
disc-broken-conn
Defines the behavior when receiving RTP broken
notification.
Enables disconnect calls on a configured silence timeout.
Enables display name to be used as source number.
