HP Latex 300 Series

16. Remove the Cover.
17. Remove T-20 screws that secure the Substrate-Axis Motor Bracket to the side-plate.
18. Remove two T-20 screws (Type A) that secure the Substrate-Axis Motor Bracket to the Chassis.
19. Remove the Substrate-Axis Motor Bracket from the printer.
242 Chapter 8 Removal and installation ENWW
