HP Latex 300 Series

10. Disconnect the Aerosol Fan cable from Interconnect PCA.
11. Remove two T-10 screws to unroute the Aerosol Fan cable from the cable clamp.
12. Unroute the Primer Assembly Valves tube from the Service Station.
13. Slide the Carriage Assembly into the print path in order to access the screws.
350 Chapter 8 Removal and installation ENWW
