HP Latex 300 Series Service Manual

14. Remove four T-20 screws (Type J) that secure the rear of the Service Station to the Chassis. Follow the
order in the picture.
CAUTION: When removing the screws 1 and 4, be very careful NOT to damage the Encoder Strip.
CAUTION: When removing the screws 2 and 3 that secure the Service Station to the X-Axis, hold the
Service station as it could fall when the screws are removed.
15. Remove the Service Station from the printer.
ENWW Service station 351
