Lexmark C792 series

To Next Page

To Previous Page

2-76 Service Manual

5062

Go Back

Check the cables in the indicated connectors for proper connection to

the system board.

133.01 Black—D (JCMKM1)

133.02 Cyan—C (JCMCY1)

133.03 Magenta—D (JCMKM1)

133.04 Yellow—C (JCMCY1)

Are the cables properly connected?

Go to step 4. Reseat the

cable.

Step Questions / actions Yes No
