2-106 Service Manual
5062
4
Open the left access door, remove the two
screws (A), and pull out the fuser autoconnect
enough to check the cable for proper
connection.
Is the cable connected correctly?
Go to step 5. Reseat the cable.
5
Check the cable for damage.
Is the cable damaged?
Replace the fuser system
card and LVPS cable. See
“Fuser system card and
LVPS cable removal” on
page 4-67.
Reseat the cable.
Step Questions / actions Yes No
