1. Check the pick assembly for mechanical
wear or damage.
2. Check if the pick arm spring is not
dislodge.
Is the pick assembly not damaged?
Go to step 7. For 550-sheet input option:
Replace the pick assembly.
See “550-sheet tray pick
assembly removal” on
page 4-176.
For 2000-sheet input
option: Replace the pick
assembly. See “2000-
sheet high-capacity
feeder pick assembly
removal” on page 4-218.
7
For 550-sheet input option: Replace the
media tray assembly. See “550-sheet media
tray assembly removal” on page 4-166.
For 2000-sheet input option: Replace the
media tray assembly. See “2000-sheet high-
capacity feeder media tray assembly
removal” on page 4-215.
Does the problem persists?
For 550-sheet input option:
Replace the 550-sheet
drawer assembly. See
“550-sheet drawer
assembly removal” on
page 4-166.
For 2000-sheet input
option: Replace the 2000-
sheet high-capacity feeder
input option.
Problem solved.
Step Questions / actions Yes No
