Lexmark C792 series

To Next Page

To Previous Page

4-172 Service Manual

5062

Go Back

9. Disconnect the three drive connectors (C) from the controller card assembly.

10. Pull up the left side of the drive assembly until the left tip (D) clears the drawer.
