Lexmark C792 series User Manual

Connector locations 5-5
5062
Go Back
Previous
Next
JCMKM1
M+K Metering
Cable: 10J0940 M+K
Cart Metering
1 VS10_CM_K
2GND
3 S_CART_MTR_K_IN
4 S_CART_MTR_M_IN
5GND
6 VS10_CM_M
JCVR1
Cover Open Switch
Cable: 10J0946 Part of
Housing
1 VDO_5V_SUPPLY
2GND
3 VDO_5V_SOURCE
4 V48_+24V_SW_FU
5 V48_+24V_SW_PS
JDDIV1
Duplexer Diverter Mtr
Cable: In FRU
1 V10_D_D_MTR-
2 V10_D_D_MTR+
JDDLED1
Duplex Door LED
Cable: 10J0948 Duplex
Door
1SDLED1 2 +5V or GND
3SDLED3 4 +5V or GND
5SDLED5 6 +5V or GND
7SDLED7 8 +5V or GND
JDIMM1 (Card Opt)
NA NA
JDP1
Duplex Paperpath Sensor
Cable: 10J0957
Duplexer
1GND 2GND
3 VS10_S2_DUP 4 VS10_DUP_PARK
5 S_S2_DUP_SNS 6 S_DUP_PARK_SNS
7NO NAME 8 S_DUP_DOOR_LED
9 S_FSR_BUBBL_SNS 10 VS10_FSR_BUBBL
11 GND 12 GND
JDUPL1
Duplex Mtr
Cable: 10J0935 Duplex
Motor
1 VS10_DUPLEX_LED
2 S_DUPLEX_ENC
3GND
4GND
5 V25_DUPLEX_MOT+
6 V25_DUPLEX_MOT-
JFMUSB
OP Panel
Cable: 10J0971 Panel
USB
USB NA
System board connectors
See “System board” on page 5-2.
Connector Pin # Signal Pin # Signal

Lexmark C792 series Specifications

General

Print Technology	Color Laser
Print Speed (Letter, Black)	50 ppm
Print Speed (Letter, Color)	50 ppm
Processor Speed	1.2 GHz
Monthly Duty Cycle	150, 000 pages
Maximum Paper Size	8.5 x 14 inches (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Connectivity	USB, Ethernet
Media Sizes Supported	A4, A5, Letter, Legal, Executive, Folio, JIS B5
Media Types Supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Input Capacity (Standard)	650 sheets
Output Capacity (Standard)	500 sheets
