5-4 Service Manual

5062

Go Back

LVPS

Cable: In FRU

1 +5V_ENG_CONN 2+5V_RIP

3 +5V_RIP 4+24v

5 +24v 6+24v

7GND 8GND

9GND 10 GND

11 GND 12 GND

13 GND 14 GND

J11

Optional hard drive

NA NA

JBLW1

Cartridge Blower

Cable: 10J0953: Blower

& RS Waste

1S_BLOW_FG

2GND

3 V20_BLT_BLOWER

4BLOW_PWM

5S_BLED5

JBUSB1 (Out)

USB NA

JCCT2

Thermistor on LVPS

Cable: 10J0974

Weather Station

1 REMOTE_WS

2GND

JCM1

C & M Block

Cable: 10J0932 BLDC C

& M

1 C_BLDC_HOME 2GND

3 C_BLDC_HALL_U 4 V45_M_WIND_W

5 C_BLDC_HALL_V 6 V45_M_WIND_V

7 C_BLDC_HALL_W 8 V45_M_WIND_U

9 C_BLDC_FG 10 +5V_SW

11 GND 12 GND

13 +RV_SW 14 M_BLDC_FG

15 V45_C_WIND_U 16 M_BLDC_HALL_W

17 V45_C_WIND_V 18 M_BLDC_HALL_V

19 V45_C_WIND_W 20 M_BLDC_HALL_U

21 GND 22 M_BLDC_HOME

JCMCY1

C+Y Metering

Cable: 10J0955 C+Y

Cart Metering

1 VS10_CM_C

2GND

3 S_CART_MTR_C_IN

4GND

5 S_CART_MTR_Y_IN

6GND

7 VS10_CM_Y

System board connectors

See “System board” on page 5-2.

Connector Pin # Signal Pin # Signal
