Lexmark C792 series

To Next Page

To Previous Page

5-8 Service Manual

5062

Go Back

JMM1

Printhead

Cable: Part of printhead

1 MM_REF_KM 2+24V_MM

3 MM_LOCK_KM 4GND

5 +3.3V_A1 6START_CY

7START_KM 8GND

9GND 10 MM_LOCK_CY

11 +24V_MM 12 MM_REF_CY

JMPF1

Multipurpose feeder sensor

Cable: 10J0929 MPF

sensor cable

1 VS10_MPF_OUT

2 S_MPF_OUT_SNS

3GND

4 VS10_MPF_SM_OUT

5 S_MPF_SM_OUT_SNS

6GND

7 +24V_DUP

8 MPF_PIO_GEN

9MPF_PIO_ENC

JOOPT1

Output Option

Cable: 10J0941 Output

Options

1 TXD1_OPT_OUT 2GND

3GND 4 RXD1_OPT_IN

5 +24V_TOPT 6GND

7 +5V_OPTS 8GND

9 F_BLDC_FG_OUT 10 V10_LVPS_FSR_RLY

JPC1

Cyan Memory

Cable: Part of unit

1 V_CART_3V

2 XP_DAT_C

3 XP_CLK_C

4GND

JPH1

Printhead

Cable: Part of printhead

Flat NA

JPH2

Printhead

Cable: Part of printhead

Flat NA

JPK1

Black Memory

Cable: Part of unit

1 V_CART_3V

2 XP_DAT_C

3 XP_CLK_C

4GND

JPM1

Magenta Memory

Cable: Part of unit

1 V_CART_3V

2 XP_DAT_C

3 XP_CLK_C

4GND

System board connectors

See “System board” on page 5-2.

Connector Pin # Signal Pin # Signal
