Lexmark C792 series - Page 601

Connector locations 5-9
5062
Go Back
Previous
Next
JPP2
Paper path Sensors
Cable: 10J0927 Paper
path
1 VS10_NNMS_LED 2 S_NNM_SNSR_IN
3GND 4 VS10_S1S
5 S_S1S_FB 6GND
7 VS10_NMS 8GND
9 S_NMS_FB 10 GND
11 VS1-_S2S 12 S_S2S_FB
JPY1
Yellow Memory
Cable: Part of unit
1 V_CART_3V
2 XP_DAT_C
3 XP_CLK_C
4GND
JRDR1
Paper path Redrive
Cable: 10J0951 (In
FRU)
1GND 2 VS10_SWS
3S_SWS_FB 4GND
5GND 6GND
7 S_ACC_JAM2_SNS 8 VS10_ACC_JAM2
JSTAG1
Staging Motor
Cable: 10J0936 Staging
Motor
1 VS10_STAGING_LED
2 S_STAGING_ENC
3GND
4 V20_STAGING_MTR-
5 V20_STAGING_MTR+
JTCVR1
Bin Full Sensor
Cable: 10J0950 Bin Full
1S_LED5 2NO NAME
3GND 4GND
5GND 6GND
7 VS10_BIN_FULL 8S_BF_IN
9GND 10 GND
11 S_RD2_SNS 12 VS10_RD2_LED
JTRAY1
Autocomp
Cable: 10J0933 Tray 1
Machine Side
1 VS10_ATO_CMP_LED 2 VS10_TRAY1_HALF
3 S_AUTOCOMP_ENC 4 S_PAPER_HALF_IN
5GND 6GND
7 V25_AUTOCMP_MT+ 8 V25_AUTOCMP_MT-
9GND 10 GND
11 S_PAPER_LOW_IN 12 S_PAPER_OUT_IN
13 VS10_TRAY1_LOW 14 VS10_TRAY1_OUT
JUSB1 (Out)
USB NA
System board connectors
See “System board” on page 5-2.
Connector Pin # Signal Pin # Signal
