6-61/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Enabling the FCP
Beta Draft Confidential
CBR: CLP 0+1 Enter the maximum length of CBR queues in the card. Once
the queue length reaches this threshold, all cells are discarded
until the queue length falls below this threshold.
This field is active only if the Enable ATM Flow Control
Processor check box is selected.
If you modify this value, you must then perform a PRAM
Sync.
CBR: EPD/CLP1
Discard
Enter the discard threshold for CBR queues for the card.
Once the queue length reaches this threshold, all circuits in
the QoS class discard cells using CLP1 discard or EPD
(depending on the circuit definition).
This field is active only if the Enable ATM Flow Control
Processor check box is selected.
If you modify this value, you must then perform a PRAM
Sync.
VBR Real Time: CLP
0+1
Enter the maximum length of VBR-RT queues for the card.
Once the queue length reaches this threshold, all cells are
discarded until the queue length falls below this threshold.
This field is active only if the Enable ATM Flow Control
Processor check box is selected.
If you modify this value, you must then perform a PRAM
Sync.
VBR Real Time:
EPD/CLP1 Discard
Enter the discard threshold for VBR-RT queues for the card.
Once the queue length reaches this threshold, all circuits in
the QoS class discard cells using CLP1 discard or EPD
(depending on the circuit definition).
This field is active only if the Enable ATM Flow Control
Processor check box is selected.
If you modify this value, you must then perform a PRAM
Sync.
VBR Non Real Time:
CLP 0+1
Enter the maximum length of VBR-NRT queues for the card.
Once the queue length reaches this threshold, all cells are
discarded until the queue length falls below this threshold.
This field is active only if the Enable ATM Flow Control
Processor box is selected.
If you modify this value, you must then perform a PRAM
Sync.
Table 6-1. Modify Card: ATM Flow Control Processor Tab Fields
