Configuring ATM PVCs
Defining a Point-to-Point Circuit Connection
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-15
You can configure a fault-tolerant PVC connection only for the following
ATM logical port types:
– UNI DCE
– UNI DTE
b. Continue with step 5.
For a RLMI PVC Connection
a. Expand the Service Names node, and select a service name from the list.
You can configure an RLMI PVC only for the following logical port types:
– UNI DCE, UNI DTE, NNI (see the Frame Relay Services Configuration
Guide
for CBX 3500, CBX 500, and B-STDX 9000)
– ATM network interworking for Frame Relay NNI
b. Continue with step 5.
For a PWE3 Circuit Configuration
a. Expand the Switches node, select a switch, and use the Cards or LPorts node
to select Endpoint 1. The endpoints must be configured for PWE3.
b. Repeat step a to select the name of the logical port for Endpoint 2.
c. Continue with step 5.
5. Verify the information in the Select Endpoints dialog box to ensure the correct
endpoints have been selected.
6. Choose OK to return to the Add PVC dialog box, which now displays the
information for the selected Endpoint 1 and Endpoint 2 Logical Ports.
7. Continue with one of the following sections, according to the ATM service you
are configuring:
• If both endpoints provide ATM services, continue with the following section,
“About the PVC Tabs” on page 10-16.
• If one endpoint provides Frame Relay services, continue with “Configuring
Frame Relay-to-ATM Interworking Circuits” on page 10-40.
• If both endpoints provide ATM services and you plan to enable PWE3
signalling, continue with “Manually Defining the Circuit Path” on
page 10-68.
